Foundation Bolt

About Foundation Bolt

Dhatvik India offers a versatile range of Foundation Bolts tailored for high-performance anchoring applications in structural, mechanical, and civil engineering sectors. Engineered with premium-grade materials and standardized thread configurations, each variant is built for strength, durability, and precision-fit installation.

All bolts are supplied with nuts and washers as per specification, and designed for dependable anchorage in concrete foundations, heavy machinery, and gearbox assemblies.

Available Types:

Type 1: Gearbox Foundation Bolt

• Drawing No.: PL1-00-001/1, Rev. R0

• Description: Foundation Bolt with Nut for Gearbox

• Size: M30 x 1000 mm

• Application: Gearbox foundation, heavy-duty base anchoring

• Material: Mild Steel

• Includes: Nut

• Special Feature: Custom-built as per drawing

Type 2: Anchor Foundation Bolt M24 x 950 mm

• Type: Anchor Type

• Size: M24 x 950 mm

• Thread Length: 200 mm

• Thread Standard: Coarse

• Material: MS

• Property Class: 8.8

• Includes: Single Nut + Lock Nut, Plain Washer

• Application: Structural steel anchoring, machine base fastening

Type 3: Bright Bar Anchor Bolt M24 x 560 mm

• Type: Anchor Type

• Size: M24 x 560 mm

• Thread Length: 175 mm

• Material: ST-37 (Bright Bar)

• Property Class: 4.8

• Includes: 2 Main Nuts + 1 Washer

• Application: General foundation fastening as per drawing

• Special Note: Manufactured as per drawing specification

Type 4: Metric Fine Thread Anchor Bolt M16 x 630 mm

• Type: Anchor Type

• Size: M16 x 630 mm

• Thread Length: 55 mm

• Thread Standard: Metric Fine

• Material: MS

• Property Class: 8.8

• Includes: Single Nut + Lock Nut, Plain Washer

• Application: Precision anchoring where fine threading is required

Common Features Across All Types:

• Material: High-grade Mild Steel / ST-37

• Thread Type: Coarse / Metric Fine

• Property Class: 4.8 / 8.8

• Accessories: Nut(s) and Washer(s) Included

• Application: Foundation fixing, concrete anchoring, industrial installations
